2013 Ford Fusion Body Structure (Hydroformed)

No comments

The 2013 Ford Fusion uses hydroformed steel tubes for its B-pillars and a hydroformed A-pillar roof rail.  So why is this important to us?  Using hydroforming instead of hot-stamped welded sheet to create the car’s roof-pillar structure reduced mass, saved cost, reduced the bill of material (which is the number of parts welded together to make the B-pillar), and helped improve the new Fusion’s crash performance. The hydroformed steel tubes replaced hot-stamped parts. B-pillars are a common place to find hot-stamped boron and the hydroformed steel tubes are replacing it in the 2013 Fusion.

2013 Ford Fusion Body Structure (Hydro-formed)

2013 Ford Fusion B-Pillar Body Structure UHSS

Take a close look at the two images below of the body structure of the previous design and the new hydroformed design.  Notice that the previous design used boron steel and the new hydroformed design does not.  I’m going to try to work some magic and see if I can get my hands on a 2013 Fusion but since it is new it might take a little time before showing up in scrap yards.

2013 Ford Fusion Body Structure A-Pillar Boron Extrication

2013 Ford Fusion Body Structure B-Pillar Boron Extrication



Posted by on November 8, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , , ,

B-pillar ‘tailor rolled’ to 8 different thicknesses

No comments

The 2013 Ford Focus is packed full of boron and other ultra-high strength steels.  But, let’s take a look at the B-pillar and the material it is made from.  The B-pillar is made from tailored rolled steel blanks that allow parts to have different thicknesses through one part.  The important nugget to take away from this is if a cutter ever stalls during a cut, simply moving the tool up or down an inch or two can allow the cut to be successful.

2013 Ford Focus B-Pillar Body Structure

Colors indicate eight different thicknesses in the B-pillar post of the forthcoming Ford Focus. The right-hand color strip starts with the thinnest sections at the bottom (four shades of blue), rising to two shades of green and then one each of yellow and orange (thickest at 2.7 mm). The eight thicknesses on the Focus B-pillar range from a maximum of 2.7 mm (0.1 in) to as thin as 1.35 mm (0.05 in). The engineering of the shape puts the greatest thicknesses where they are needed for maximum strength in side impacts, and in the case of the B-pillar it’s just above the midpoint (orange area in illustration).

Check out the body structure of the 2012 Ford Focus which is carried over into the 2013 model.

Posted by on November 6, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , ,

2012 Jeep Patriot Body Structure

No comments

Check out the body structure and safety features in the 2012 Jeep Patriot.

2012 Jeep Patriot Body Structure
  • Advanced multistage front airbags that adjust airbag output to crash severity
  • Supplemental side-curtain front and rear airbags+ offer side protection for all of the outboard occupants
  • Available supplemental front seat-mounted side airbags
  • Engineered crush zones divert and dissipate impact energy away from the passenger compartment
  • Safety cage structure and front crumple zones absorb energy during a front impact
  • Door guard beams help protect occupants during side impact
  • Ultra high-strength roll-formed steel crossbeam helps transfer side-impact energy from one side of the car to the other

2012 Jeep Patriot Body Structure

Posted by on August 27, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , ,

2013 Volvo C70 Body Structure and Safety Systems

No comments

Here is a quick look at the 2013 Volvo C70.  The doors and B-pillars have been reinforced in various ways.  In a side impact the doors and B-pillars work together with the reinforced sills and a comprehensive system of cross-members and bulkheads to absorb the collision forces.

2013 Volvo C70 Body Structure Safety ROPS

The C70 retractable hardtop also features a roll over protection structure (ROPS) with two pyrotechnically charged roll hoops hidden behind the rear seats that deploy under roll-over conditions whether the roof is retracted or not.2013 Volvo C70 Body Structure Safety BIW

2013 Volvo C70 Body Structure Safety

Take a look the screen shot from Moditech’s Crash Recovery System.  Notice that the B-pillars don’t show any advanced or reinforced steel?  Just remember, most convertibles have a very large B-pillar structure behind the sheet metal.

2013 Volvo C70 CRS Moditech Extrication Safety Airbag

2006-2013 Volvo C70 Body Structure

Extrication Airbag Door

Extrication Airbag Door

Posted by on May 29, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , , , , ,

Audi A5 Body Structure

No comments

Here’s a quick look at all the different steels in the Audi A5.

Audi A5 Body Structure Extrication

Audi A5 Sportback body structure BIW

Posted by on May 24, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , ,

Advanced Steel Extrication PowerPoints

2 comments
Below are the advanced steel PowerPoints I presented at the Train the Trainer in Ann Arbor Michigan.  Feel free to use, share, and change it fit your departments needs.  Also, please let me know of anything you think should change.
Posted by on May 5, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , , , , , , , ,

2013 Hyundai Santa Fe Body Structure

No comments

The all-new architecture incorporates a new design that not only improves distortion rigidity by 16 percent, it also incorporates a 30-percent increase in the use of ultra high-strength-tensile steel to improve collision energy management. High-strength steel also allows the suspension to work optimally and reduces weight. Ultra-high strength tensile sheet metal has also been applied to the outer door panels for the first time in the company’s history. In addition, anti-corrosion steel was applied to 70 percent of outer frame and floor structure.

2013_Hyundai_Santa_Fe_body_Structure_Extrication

New hot stamping and roll forming methods have also been applied to impact members, which provide added strength, reduces the number of body parts and makes the architecture lighter. The amount of structural adhesives has also been increased significantly for improved body rigidity, crashworthiness and durability.

Posted by on May 2, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , ,

Crash Recovery System for Android in April!

No comments

The very fine folks at Moditech annouced in their latest newsltter that the Crash Recovery System for Android will be availible in April!  The availability of the Crash Recovery System for different hardware platforms is a declared objective of Moditech Rescue Solutions B.V. This allows our users maximum flexibility in selection of the necessary hardware. Among the CRS editions for different versions of the Microsoft Windows operating system and the Apps for the Apple iPhone and Apple iPad the Crash Recovery System family will soon become two additional members.

Currently, two apps for devices with the operating system Android are in the works. CRS Lite for Android will be specifically designed for users of Android smartphones and will have similar functions as the CRS Lite Edition and iCRS Lite for iPhone. For users of Android Tablet PCs the App CRS Standard for Android is under development, covering similar functions as the CRS and iCRS Standard Editions, joining the vehicle graphics with extensive illustrated background and deactivation information.

Posted by on March 6, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , , , , , ,

Body Structure: Impact-absorbing body and high-strength cabin

No comments

Toyota used the image below to simply explain how an impact absorbing body and a high strength cabin protects occupants. Just remember, the toughest still will be in the cabin area but can extend into the impact absorbing area too.  Never assume your cutters cannot cut any part of the vehicle, if your cutters stall, go to plan b.  Plan B can be as simple as repositioning the tool.

In order to help reduce the impact on the occupants during a collision and reduce cabin deformation, crumple zones at the front and rear of the vehicle absorb the impact with high efficiency. The cabin uses a body structure that is strong and does not deform easily. To help protect occupants during side collisions, where little crumple zone is available, a high-strength body frame, including the center pillar and the floor cross member, absorbs the impact with decreased deformation.

Posted by on February 26, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , ,

Detroit bound from a great West Coast Extrication Trip!

No comments

Well the West Coast Extrication trip is over, all that is left to get on the plane and head home back to Detroit.   The bad part is it was almost 80 degrees today in Redwood and it snowed in Detroit last night.  The plan is to break down the trip into a 3 part post. Brock Archer from AdvancedExtrication.com hooked me with a great exposure to West Coast Extrication.  Which is not different from everyone else except they get to train in warm weather in February!

The first will be the classroom portion that Ron Moore from Firehouse Magazine presented.  The second will be the school bus extrication with the scrap yard workers showing how fast they can rip apart a bus.  The final part will be a rundown of the extrication techniques and evolutions covered over the two days of hands on training.

Posted by on February 24, 2012 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , , , , , , , ,

2012 Holden Commodore Body Structure (Au)

1 comment

Here is a quick post for our readers from Australia, The Holden Commodore body structure.  The B-pillar (yellow) is Ultra High Strength Steel for cab protection in side impacts.








Posted by on December 15, 2011 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , , , , ,

So the Chief asks, Can Your Extrication Tools Cut It?

No comments

Check out this FIREGROUND Flash Tip episode, Chief Wylie compares using different hydraulic cutters to cut through the boron treated steel found on many of today’s automobiles.  Chief Wylie even plugs our friends over at Extraction Zones LLC!!

FlashoverTV is powered by FireRescue1.com

Just remember, if your tool is outgunned during a cut, go to plan B! Plan B can be as simple as moving the tool up or down a few inches. Remember my post about tailored blanks? If you are asking what’s a tailored blank?  Give it a quick read, then add that little nugget of info into your mental tool box!

Posted by on November 30, 2011 • Filed under: extrication, special-operations • Tagged: , , , ,

2012 Chevrolet Sonic Body Structure

No comments

The body structure of the all-new 2012 Chevrolet Sonic sedan and hatchback. Nearly 60 percent of the body structure, as well as the four-mount hydro-formed engine cradle, use high-strength steel. Ultra-high-strength steel is strategically integrated in the forward portion of the rockers and the center cross bar.

© Copyright General Motors

The reinforced front hinge and A- and B-pillar zones help maintain the integrity of the passenger compartment.  The roof is capable of supporting up to four times the car’s weight.

© Copyright General Motors

© Copyright General Motors

© Copyright General Motors

The all-new 2012 Chevrolet Sonic is the only vehicle in its class with 10 standard airbags. . The Sonic features dual-stage airbags for the driver and the front passenger and roof-rail mounted head curtain airbags and seat mounted side-impact airbags for front and outboard rear seat passengers as standard. A driver knee air bag and a segment-exclusive front passenger knee air bag are included to reduce injury to lower extremities.

© Copyright General Motors

© Copyright General Motors

On the hatchback, the door handles are concealed in the C-Pillar and are rendered in black, as is the trim, giving the car the appearance of a two-door hatchback.

Posted by on November 11, 2011 • Filed under: extrication, special-operations • Tagged: , , , , , , , , , ,

Free Rescues Cards For Your Phone, Thanks Opel!

No comments

One day after I posted about an app for the iPhone  and iPad called Extraction Zones I ran across a rescue website that can be used on any Smartphone connected to the Internet.  Another European automaker, Opel, stepped up to the plate and put an extremely useful rescue tool in the hands of many first responders for free!  Opel put Rescue Cards that contain information for some 60 models from 1991 to present on a mobile portal that can be used on any Smartphone which has access to the Internet. This free mobile service is available in 10 European languages and enables rescue crews to access important information instantly.

The mobile rescue card portal will be used primarily by the fire department and first response crews. Via www.opel-rescuecard.com they can choose their own language and run a search for any Opel model. By placing the information on the Internet, rescue crews can be assured they are receiving the latest, most up-to-date news. Thanks to the built-in page optimization, the mobile rescue card portal automatically adapts to every standard smartphone model. The zoom function ensures that single parts and body sections can easily be seen on a small display.

If you don’t have a Smartphone, don’t worry, the rescue cards are still downloadable as PDF-files via the Internet.

Rescue Cards Extrication

Rescue Cards Extrication

Rescue Cards use the common key to show the different hazards in vehicles.  The key is very similar to the one Moditech uses in their Crash Recovery System.  Interesting…..maybe the Moditech Pioneers had a hand in developing the Rescue Cards for Opel.

Images and information from Opel Media

Posted by on April 20, 2011 • Filed under: extrication • Tagged: , , , , , , , , , ,

Hurst FDIC Display

No comments

Hurst….. Well every major extrication tool manufacturer had a great display of tools set up at FDIC.  Hurst had a 2011 Ford Fiesta in a plexi-glass box where factory reps cut it to pieces in front of visitors at their booth.  There was also a stack of Boron B-pillars that I would have loved to sneak out the back.  There was also an outside demo area by Lucas Oil Stadium where conference attendees could put on some PPE and make some cuts on a car.  Best part of the outside demo on Friday was Hurst had a bar set up next to the display!

Posted by on March 28, 2011 • Filed under: extrication • Tagged: , , , , , , ,

Thanks for a Great 2010!!!!

No comments

What a great year 2010 was! For the first time in a long time the automotive industry started adding jobs here in Detroit! Hopefully, with more people getting back to work the budget cuts in public safety budgets can finally start to slow down, if not end!

As for BoronExtrication.com, I started this blog to help spread around information about the advanced steels used in the body structure of new vehicles. Back in January, I would have never guessed how much traffic to my blog would increase! Also, becoming part of the FireEMSBlogs.com family was huge honor and a great step to gain a larger readership.




One cool thing about writing this blog is all the contacts and people I get to meet in the Fire Service. First off, in May I went to a trauma synopsis at local community college that Ron Moore from Firehouse.com and University or Extrication was presenting at. To my shock, Ron knew who I was when I went up to meet him.

Dave Dalrymple and his crew from RoadwayRescue LLC



Another gentleman I met was Dave Dalrymple and his crew from RoadwayRescue LLC at a DVD filming for Fire Engineering in Dearborn, Michigan. Extrication is not limited to the US. From Canada there is Randy Schmitz from the Calgary Fire Department and Alberta Vehicle Extrication Association. The reach of the internet connects me to a friend across the pond in the UK, Jon Curley from rtc-rescue.com. Last but not lest is the FireEMSBlog.com group of bloggers and support staff. While I have yet to meet any of them face-to-face, they all are a true asset to the Fire Service and I’m looking forward to a great New Year!

Please everyone on-duty tonight or like me, skipping the alcohol just incase there’s a MVA on the freeway (fires or even more rare in Wixom, MI), stay safe out there!!

Posted by on December 31, 2010 • Filed under: extrication, fire-rescue-topics • Tagged: , , , , , , , , ,

2007-2010 Subaru Impreza WRX STi Body Structure

2 comments

Just remember, most Subarus are going to made of a ton of Boron and other UHSS.  The Subaru Impreza WRX STi is no different.  Just take a look at all the red colored pieces of the body structure below.

Posted by on December 30, 2010 • Filed under: extrication • Tagged: , , , , , , , , ,

2011 Honda CR-Z Sport Hybrid Coupe Body Structure

No comments

The Body Structure of the 2011 Honda CR-Z is made up with 45% high-strength steel (590 MPa or above).



2011 Honda CR-Z Advanced Compatibility Engineering (ACE) body structure

2011_Honda_CR-Z_High-Strength_Steel_Body_Structure_ACE





Most likely you looked at the image above and asked why does the windshield interface matter during an extrication?  The 2011 Honda CR-Z has a thin A-pillar design that measures 108.8 mm in minimal thickness to improve forward visibility.  Why it really matters is the A-pillar get strength through the use of high-grade, high-tensile steel of class 780MPa.

Also make sure you read through Honda’s Emergency Response Guide ERG.

Source of images and information: Honda Media Newsroom

Posted by on November 16, 2010 • Filed under: extrication, fire-rescue-topics, rescues, training-fire-rescue-topics • Tagged: , , , , , , , ,

2011 Hyundai Genesis Body Structure

No comments

The body structure of the 2011 Hyundai Genesis is made from an Ultra High Strength Steel (UHSS) uni-body.  This is the first line of defense for the passengers inside the Genesis’s cabin.  Hyundai has engineered advanced crumple zones to absorb and redirect forces away from the passenger cabin. 2011-hyundai-genesis-body-structure

Genesis body-in-white is made of the following types of steel: High-strength steel (HSS) (56.7%), shown in green, and Ultra-high-strength steel (UHSS) (18.3%), shown in orange/red. That totals to 75%.

2011 Hyundai Gensis Boron Extrication Body Structure Airbag UHSS

There are 8 airbags in the Genesis, including 2 front, 2 rear seat, dual front-advanced, and roof-mounted curtain side impact bags.   An added safety feature in the seat is the active front head restraints that protect against whiplash in a rear collision.  These whiplash protection systems have started to make there way into more vehicles.  When the systems were first used the cost was too high so you would only find them in high end vehicles.  The systems work very well!

Posted by on November 9, 2010 • Filed under: ems-topics, extrication, fire-rescue-topics • Tagged: , , , , , , , , , , , , ,

Reciprocating Saws vs Boron Steel

1 comment

Take a look at a test my friend across the Pond did on cutting boron steel with a reciprocating saw (or Sawzall if you are a Milwaukee Electric Tool fan).  Basically, John from RTC Rescue over in the UK shows that a reciprocating saw is useless trying to cut thru the boron directly. Boron steel will remove and or round the teeth on reciprocating saw blades.  That fact is really nothing new.  Blade manufacturers are working on improving the cutting ability of the blades.   Check the video out, John tries to cut the B-Pillar from a 2009 Mercedes C-Class with different blades and models of saws with no luck.

Posted by on November 2, 2010 • Filed under: extrication, fire-rescue-topics • Tagged: , , , ,

2011 Ford Fiesta Boron Body Cage

1 comment
Over 50% of the new 2011 Ford Fiesta’s body structure is constructed out of lightweight, incredibly high-strength Boron steel.  The use of Boron Steel is borrowed from Volvo. However, the super steel compound was only used in select key areas, including the Fiesta’s floor structure, front rails and beams, and the integrated “body-side reinforcement.” Essentially an extremely complex roll cage, the primary structural components of the body-side reinforcement include the slim A-pillar, the intrusion-resistant B-pillar, the rocker panels to which the B-pillar is fixed, the stabilizing rocker baffles, side roof arch and the lower A-pillar.

Posted by on June 14, 2010 • Filed under: Uncategorized • Tagged: , , , ,

OnStar, GM will give Volt first responder training

No comments
The Detroit News has an article today about GM’s plan to offer training to first responders.  I spoke with Ron Moore last month from Firehouse.com’s University of Extrication and he told me that he recently visited the GM proving grounds to cut up a new Chevrolet Volt. Aside from all the battery and electric concerns.  He said that this vehicle has some really strong Dual Phase steel to consider also.
GM is offering training on the new Chevrolet Volt for first responders. If you are having trouble watching the video, click here.

During the past several months, Chevrolet has collaborated with first-responder representatives from national safety organizations to develop educational materials for firefighters, law enforcement, emergency medical technicians and emergency dispatchers nationwide. This will help ensure the training meets the needs and answers the questions their colleagues are likely to have about electric vehicles.



Their feedback is being incorporated into training materials that will be available on the tour and posted on a targeted Web site for departments unable to attend the training sessions.

The training will include animation and illustrations of the Chevrolet Volt, highlighting locations of high-strength steel, cut points for extrication, first-responder labeling, automatic and manual electrical shut-off and more.

Notice the last sentence in the quotes?  There are going to be cut points for extrication and first-responder labeling!   A true step in the right direction to help us get our patients out quickless.

Make sure you are a Fan of Boronextrication.com on Facebook!
Posted by on June 2, 2010 • Filed under: extrication, fire-rescue-topics, rescues, special-operations, training-fire-rescue-topics • Tagged: , , , , , ,

2010 Volvo V60 Body Structure Safety Cage

No comments

Real quick look at the 2010 Volvo V60 Body Structure and Safety Cage.

2010 Volvo V60 Body Structure Safety Cage

Posted by on May 29, 2010 • Filed under: extrication, special-operations • Tagged: , , , , , , ,

2012 Ford Focus has Boron!

1 comment

Next year when Ford starts selling the 2012 Focus First Responders will have another vehicle packed with UHSS and Boron steels.  The new Focus is 25 percent greater torsional rigidity than the current North American Focus. The different strenghs of steel is broken down high-strength steel for 55% of the body shell with 26% of the structure formed from ultra-high-strength Boron steels.  Just an FYI, this is more than any other Ford vehicle.

Posted by on March 3, 2010 • Filed under: extrication • Tagged: , , , , , , ,

2010 Ford Taurus Boron, UHSS, and Body Structure

1 comment

Below are a couple of 2010 Ford Taurus pictures of the UHSS and Boron steel used.  The red is the UHSS and Boron.  The B-Pillar is made with Boron. My department ran on an MVA with a new 2010 Taurus and our Hurst MOC II Cutters made easy work cutting thru the B-Pillar.

Ford uses SPACE Architecture which stands for Side Protection And Cabin Enhancement What is interesting about the 2010 Taurus, is a hydroformed cross-car beam embedded in the floor between the door frames.  During a side impact crash, the beam helps divert crash forces away from the occupants. The roof is also tied into the floor beam. A strong roof crossmember and side-impact door beams work with the floor-mounted tube to further enhance side-impact protection.
